EMI Shielding Gaskets

Custom gaskets protect components against electromagnetic interference (EMI)

EMI shielding gaskets protect electronic devices and components from electromagnetic interference (EMI) and radio frequency interference (RFI)

Power supplies, motors and other energy sources can generate unwanted electromagnetic signals that interfere with the functions of critical electronic devices and components. This creates a technical challenge for many OEMs that incorporate electronics in their products.

We convert shields, foam tapes and materials such as particle-filled silicone into EMI shielding solutions for electronic devices, helping guard against device malfunction or failure. We can custom fabricate them to your exact specifications and requirements for tensile strength, tear resistance and thermal stability/conductivity.

Benefits

Particle-filled silicones offer the performance characteristics of silicone with the electrical properties of metals. They can contain aluminum, copper, graphite, nickel or silver. EMI shielding gaskets don’t just inhibit electrical and radio frequency interference (RFI); they also withstand abrasion, chemicals and extreme temperatures.
They offer:

  • Voltage endurance
  • Thermal conductivity
  • Excellent dielectric strength
  • Mechanical toughness

Applications

Appliance controls
Electronic devices
Automotive controls
Electrical insulation
Circuit breakers

Materials

BISCO EC-2130 Silicone EMI Shields
Nomex Type 410
Formex Polypropylene
SSP EMI / RFI Conductive Silicones

Design

As you develop products that need EMI or RFI protection, ask these questions.

Gasket function

Gasket function

Do you need the gasket to do more than block EMI or RFI, such as sealing out liquids, solids or air, or mitigating shock or vibration?
Gasket size

Gasket size

Are there limitations on gasket format (die cut vs. stripping)?
Gap spacing

Gap spacing

What is the thickness range of the gap?
Temperature

Temperature

What high and low temperatures will the material reach and for how long?
UV/Ozone resistance

UV/Ozone resistance

Will the material be directly exposed to the elements?
Flame rating

Flame rating

Does your application include requirements like UL-V0, UL-HBF or FMVSS-302?
Chemical resistance

Chemical resistance

Will the material be in contact with chemicals or fluids?
Outgassing

Outgassing

Could material outgassing be detrimental to components?
Color

Color

Will a particular color improve ease of assembly or help with future inspections?
Cost and performance

Cost and performance

Does your application require a premium product?

Featured Material: BISCO EC-2130

BISCO® EC-2130 is a soft electrically conductive silicone used to reduce EMI and RFI to protect critical electrical components. Its combination of extra soft polymer and highly conductive filler creates an environmental seal. BISCO EC-2130 electromagnetic shield conductive silicones reduce EMI and RFI at frequencies above 10 GHz in a wide range of electronic applications.

Key Features
  • Available thicknesses of 0.063 to 0.125 in.
  • +100 db shielding effectiveness
  • Grade: Silicone EMI Shields
  • Durometer: Shore OO 80 ±1
Benefits
  • Low durometer creates low compressive forces
  • Designed to meet specific design needs for compact handheld electronics, communication devices, electronic enclosures and laptop computers
Applications

EMI Shielding
EMI Gasketing
EMI Sealing
